System Specifications

RG-S6250-48XS8CQ

Ports

48 x 10GE ports and 8 x 100GE ports

Expansion Modules

Power supply module slots

Fan module slots

Management Port

One management port, one console port, and one USB port (compliant with the USB2.0 standard)

Switching Capacity

2.56Tbps

Packet Forwarding Rate

1920 Mpps

802.1Q VLAN

4094

Dimensions and Weight

Dimensions
(W × D × H)

442 mm × 387 mm × 44 mm (17.40 in. x 15.24 in. x 1.73 in.), 1 RU

Weight

8 kg (17.64 lbs., including two power supply modules and four fan modules)

Power Supply and Consumption

AC

Rated voltage range: 100 V AC to 240 V AC

Maximum voltage range: 90 V AC to 264 V AC

Frequency: 50 Hz to 60 Hz

Rated input current: 3.5 A to 7.2 A

High-Voltage DC (HVDC)

Input voltage range: 192 V DC to 288 V DC

Rated input current: 3.6 A

Low-Voltage DC (LVDC)

Input voltage range: –42 V DC to –72 V DC

Rated input voltage: –48 V DC

Rated input current: 23 A

Maximum Power Consumption

300 W

Environment and Reliability

Operating Temperature

0°C to 45°C (32°F to 113°F)

Storage temperature

-40 °C to 70 °C (-40 °F to 158 °F)

Operating Humidity

10% to 90% RH (Non-condensing)

Storage humidity

5% to 95% RH (non-condensing)

Working altitude

Operating altitude: up to 5000 m (16,404.20 ft.)
Storage altitude: up to 5000 m (16,404.20 ft.)

Software Specification

RG-S6250-48XS8CQ

L2 Protocols

IEEE802.3ad (Link Aggregation Control Protocol), IEEE802.1p, IEEE802.1Q, IEEE802.1D (STP), IEEE802.1w (RSTP), IEEE802.1s (MSTP), IGMP Snooping, MLD Snooping, Jumbo Frame (9 KB), IEEE802.1ad (QinQ and selective QinQ), and GVRP

L3 Protocols (IPv4)

BGP4, OSPFv2, RIPv1, RIPv2, MBGP, LPM Routing, Policy-based Routing, Routing Policy, ECMP, WCMP, VRRP, IGMP v1/v2/v3, PIM-SSM/SM/DM, MSDP, and Any-RP

Basic IPv6 Protocols

Neighbor Discovery, ICMPv6, Path MTU Discovery, DNSv6, DHCPv6, ICMPv6, ICMPv6 redirection, ACLv6, TCP/UDP for IPv6, SNMP v6, Ping/Traceroute v6, IPv6 RADIUS, Telnet/SSH v6, FTP/TFTP v6, NTP v6, IPv6 MIB support for SNMP, VRRP for IPv6, and IPv6 QoS

IPv6 Features

Static routing, ECMP, PBR, OSPFv3, RIPng, BGP4+, MLD v1/v2, PIM-SMv6, manual tunnel, automatic tunnel, IPv4 over IPv6 tunnel, and ISATAP tunnel

ACL

Standard IP-based ACL、Extended MAC/IP-based ACL、Expert-level ACL、ACL 80、IPv6 ACL、When the same ACL is applied to different physical interfaces or SVIs, resources can be multiplexed.、ACL Logging、ACL Counter (Ingress and egress counters are supported in interface or global configuration modes)、ACL Re-marking、Global ACL、ACL-based Redirection、Displaying ACL Resources、Processing First Packet of TCP Handshake When Binding the ACL to Restrict SIP、Matching Against 5-Tuple of Pass-by VXLAN Inner IP Packets、The expert-level ACL supports matching the IP flag and DSCP fields of VXLAN inner packets、Ingress/Egress ACLs

Multicast

IGMPv1, v2, v3、IGMP Host Behavior、Member Query and Response、Querier Election、IGMP Proxy、Multicast Static Routing、MSDP、PIM-DM、PIM-SM、PIM-SSM、Enabling PIM on Layer-3 Subinterface、PIM-SMv6、MLD v1 and v2、MLD Proxy、Enabling PIMv6 on Layer-3 Subinterface

Data Center Features

VXLAN routing and VXLAN bridging

IPv6 VXLAN over IPv4
EVPN VXLAN

PFC and ECN

M-LAG

OpenFlow 1.3

Visualization

gRPC

sFlow sampling

QoS

802.1p, DSCP, and ToS priority mapping
ACL-based traffic classification
Priority marking and remarking
Queue scheduling mechanisms, including SP, WRR, DRR, SP+WRR, and SP+DRR
Congestion avoidance mechanisms, including WRED and trail drop

MPLS

* MPLS VPN

Virtualization

Virtual Switching Unit (VSU)

Cache Management

Cache status monitoring and traffic microburst identification

HA Design

GR for RIP/OSPF/BGP, BFD, DLDP, REUP dual-link fast switching, RLDP unidirectional link detection, 1+1 power redundancy, fan redundancy, and hot swapping for all line cards and power supply modules

Security Features

Network Foundation Protection Policy (NFPP), CPU Protection Policy (CPP), DDoS attack defense, unauthorized data packet detection, data encryption, source IP spoofing prevention, IP scanning prevention, RADIUS/TACACS, IPv4/v6 packet filtering by basic ACL, extended ACL or VLAN-based ACL, plaintext-based and MD5 authentication for OSPF, RIPv2, and BGPv4 packets, Telnet login and password mechanisms for restricted IP addresses, uRPF, broadcast packet suppression, DHCP Snooping, ARP spoofing prevention, ARP check, and hierarchical user management

Management Modes

SNMP v1/v2c/v3, Telnet, Console, MGMT, RMON, SSH v1/v2, FTP/TFTP, NTP, Syslog, SPAN/RSPAN/ERSPAN, Telemetry, ZTP, NETCONF, Python, fan and power supply alarming, and over-temperature alarming

Other Protocols

DHCP Client, DHCP Relay, DHCP Server, DNS Client, UDP Relay, ARP Proxy, and Syslog

Specification

RG-S6250-48XS8CQ

Safety

● IEC 62368-1

● EN 62368-1

● NM EN 62368-1

● NM CEI 62368-1

● EN IEC 62368-1

● BS EN IEC 62368-1

● UL 62368-1

● CSA C22.2#62368-1

● GB 4943.1

Electromagnetic Compatibility (EMC)

● EN 55032

● EN 55035

● EN IEC 61000-3-2

● EN IEC 61000-3-3

● EN 61000-3-3

● EN 300 386

● ETSI EN 300 386

● NM EN 55035

● NM EN CEI61000-3-2

● NM EN 61000-3-3

● CNS 13438

● FCC CFR Title 47, Part 15, Subpart B

● ANSI C63.4-2014

● ICES-003 Issue 7

● GB/T 9254.1

Environment

● 2011/65/EU EN 50581

● 2012/19/EU EN 50419

● (EC) No.1907/2006

● GB/T 26572
