Hardware Specifications

RG-S5750-24SFP4XS24DP-UP

Port

24 x 1000M SFP ports, 4 x 1G/10G SFP+ ports, and 24 x power output ports

Switching capacity

128 Gbps

Packet forwarding rate

96 Mps

Power module slot

3

Power module type

Available model: RG-PA600I-P-F

AC input

Rated voltage range: 200 V AC to 240 V AC

Maximum voltage range: 176 V AC to 264 V AC

Frequency: 50 Hz to 60 Hz

Rated current per input: 8 A

Available model: RG-PA1000I-P-F

AC input

Rated voltage range: 200 V AC to 240 V AC

Maximum voltage range: 176 V AC to 264 V AC

Frequency: 50 Hz to 60 Hz

Rated current per input: 8 A

SFP port

1000Base-X

100Base-X

SFP+ port

10GBase-R

1000Base-X

RTC

Supported

Power consumption

< 85 W

Operating temperature

0°C to 45°C (32°F to 113°F) at the altitude of 0 m to 1,800 m (0 ft. to 5905.51 ft.)

At the altitude ranging from 1800 m (5905.51 ft.) to 5000 m (16404.20 ft.), the temperature decreases by 1°C (1.8°F) each time the altitude increases by 220 m (721.79 ft.).

Storage temperature

–40°C to +70°C (–40°F to +158°F)

Operating humidity

10% to 90% RH

Operating altitude

0 m to 5000 m (0 ft. to 16404.20 ft.)

Storage humidity

5% to 95% RH

Fan module

Fan speed regulating and fault alarms

Temperature alarms

Supported

EMI

GB/T9254.1-2021 Class A

Safety standard

GB4943-2011

Dimensions (W x D x H)

442 mm x 420 mm x 43.6 mm (17.40 in. x 16.54 in. x 1.72 in.)

Weight (including power modules)

10 kg (22.05 lbs)

Software Specifications

RG-S5750-24SFP4XS24DP-UP

802.1Q VLAN

4K 802.1Q VLAN

Port-based VLAN

MAC address-based VLAN

Private VLAN

Voice VLAN

GVRP

QinQ

Basic QinQ

Selective QinQ

ACL

Standard IP ACLs (hardware ACLs based on IP addresses)

Extended IP ACLs (hardware ACLs based on IP addresses or TCP/UDP port numbers)

Extended MAC ACLs (hardware ACLs based on source MAC addresses, destination MAC addresses, and optional Ethernet type)

Time range-based ACL

Expert-level ACLs (hardware ACLs based on flexible combinations of the VLAN ID, Ethernet type, MAC address, IP address, TCP/UDP port number, protocol type, and time range)

ACL80

IPv6 ACL

Global ACL

ACL redirection

QoS

Traffic identification on an interface

Rate limiting on an interface

Traffic classification based on 802.1p priorities, DSCP priorities, and IP precedences

Eight queues on each interface

SP, WRR, SP+WRR, and RED/WRED

Mirroring

1:1 mirroring, N:1 mirroring, and 1:N mirroring

RSPAN

Local and remote flow-based mirroring

DHCP

DHCP server

DHCP client

DHCP snooping

DHCP relay

DHCPv6 snooping

DHCPv6 client

DHCPv6 relay

Security

Binding of IPv4 addresses, MAC addresses, and interface numbers

Binding of IPv6 addresses, MAC addresses, and interface numbers

Filtering unauthorized MAC addresses

Interface- and MAC address-based 802.1X authentication

MAB

Portal and Portal 2.0 authentication

ARP check

DAI

ARP rate limiting

ARP spoofing prevention

Broadcast storm suppression

Hierarchical management and password protection

RADIUS and TACAS+

AAA (IPv4/IPv6) for device login management

SSH and SSHv2.0

BPDU guard

IP source guard

CPP and NFPP

Port security

Ring network protocol

ERPS (G.8032), compatibility with third-party ERPS-capable products

PoE

IEEE 802.3af and 802.3at

Automatic and energy-efficient power supply management modes

Warm start

Scheduled power-on and power-off of PoE ports based on the time range

Port priority

IP routing

IPv4/IPv6 static route

RIP, RIPng, OSPFv2, OSPFv3, BGP, and IS-IS

Routing Policy

Basic IPv6 protocols

IPv6 addressing, ND, ICMPv6, IPv6 ping, IPv6 tracert, and IPv6 multicast

SAVI

Defense against NS/NA/RS/RA packet attacks

Preventing private IPv6 address allocation

Unauthorized terminal information buffering

VSU

Local and remote stacking

Link bundling across the chassis inside the VSU

Virtualization through standard service interfaces

Zero Touch Provisioning (ZTP)

CWMP (TR069)

Management

SNMPv1/v2c/v3, CLI (Telnet/console), RMON (1, 2, 3, 9), SSH, Syslog, NTP/SNTP, web, debugging, FTP, TFTP, sFlow, and Ruijie Cloud
