Hardware Specifications

RG-S2915-48GT4MS-L

RG-S2915-24GT4MS-L

RG-S2915-24GT4MS-P-L

RG-S2915-10GT2MS-P-L

Interface Specifications

Fixed Service Ports

48 × 10/100/1000BASE-T ports, 4 × 1GE/2.5GE SFP ports

24 × 10/100/1000BASE-T ports, 4 × 1GE/2.5GE SFP ports

24 ×

10/100/1000BASE-T ports, supporting PoE/PoE+

4 × 1GE/2.5GE SFP ports

10 × 10/100/1000BASE-T ports, ports 1 to 8 supporting PoE/PoE+,

2 × 1GE/2.5GE SFP ports

Power modules

1 fixed power module

1 fixed power module

1 fixed power module

1 fixed power module

Fans modules

2 fixed fans

0

2 fixed fans

1 fixed fans

Fixed management ports

1 × RJ45 Console, 1 × USB port

1 × RJ45 Console, 1 × USB port

1 × RJ45 Console, 1 × USB port

1 × RJ45 Console, 1 × USB port

System Specifications

Packet forwarding rate

87 Mpps

51 Mpps

51 Mpps

22.5 Mpps

Switching capacity

116Gbps

68Gbps

68Gbps

30Gbps

MAC Table Capacity

16,000

16,000

16,000

16,000

ARP table

512

Routing Table Size (IPv4/IPv6)

64

ACL entries

500

Dimensions and Weight

Dimensions (W x D x H)

440 mm × 220 mm × 43.5 mm (17.32 in × 8.66 in × 1.71 in), 1 RU

440 mm × 220 mm × 43.5 mm (17.32 in × 8.66 in × 1.71 in), 1 RU

440 mm × 292 mm × 43.6 mm (17.32 in × 11.50 in × 1.72 in), 1 RU

297 mm × 170 mm × 44.5 mm (11.69 in × 6.69 in × 1.75 in), 1 RU

Weight

2.8 kg (6.17 lbs)

2.5 kg (5.51 lbs)

2.8 kg (6.17 lbs)

2.5 kg (5.51 lbs)

CPU and Storage

CPU

Built-in CPU, single-core processor, with the clock speed of 1.2 GHz

Flash Memory

64 MB

SDRAM

512 MB

Data packet buffer

 512 KB

Power and Consumption

Maximum power consumption

< 30 W

< 15.6 W

< 33 W (non-PoE)

< 403 W (PoE full load)

< 16 W (non-PoE)

< 141 W (PoE full load)

Rated input voltage

100 V AC to 240 V AC, 50 Hz to 60 Hz

100 V AC to 240 V AC, 50 Hz to 60 Hz

100 V AC to 240 V AC, 50 Hz to 60 Hz

100 V AC to 240 V AC, 50 Hz to 60 Hz

Maximum input voltage

90 V AC to 264 V AC, 50 Hz to 60 Hz

90 V AC to 264 V AC, 50 Hz to 60 Hz

90 V AC to 264 V AC, 50 Hz to 60 Hz

90 V AC to 264 V AC, 50 Hz to 60 Hz

Environment and Reliability

MTBF

>200K

>200K

>200K

>200K

Operating Temperature

0°C to 45°C (32°F to 113°F)

Storage Temperature

-40°C to +70°C (-40°F to +158°F)

Operating Humidity

10% to 90% RH (non-condensing)

Storage Humidity

5% to 95% RH (non-condensing)

Operating noise

≤ 37 dB

Fanless

≤ 39 dB

≤ 37 dB

Interface surge protection

Power port: 6 kV/2 kV

Telecom port: 10 kV

Power port: 6 kV/2 kV

Telecom port: 10 kV

Power port: 6 kV/2 kV

Telecom port: 10 kV

Power port: 6 kV/2 kV

Telecom port: 10 kV
