Model

RG-NBS3200-24GT4XS

RG-NBS3200-24GT4XS-P

RG-NBS3200-24SFP/8GT4XS

RG-NBS3200-48GT4XS

RG-NBS3200-48GT4XS-P

Basic

10/100/1000Base-T ports

24

24

8 (Combo)

48

48

SFP ports

-

-

24

-

-

SFP ports

4

4

4

4

4

PoE/PoE ports

FALES

24

FALES

FALES

48

Max. PoE budget

-

370W

-

-

370W

Layer Type

Layer 2

Layer 2

Layer 2

Layer 2

Layer 2

Switching capacity

128 Gbps

128 Gbps

128 Gbps

176 Gbps

176 Gbps

Forwarding rate

95.24 Mpps

95.24 Mpps

95.24 Mpps

130.95 Mpps

130.95 Mpps

Packet Buffer

12 Mbit

12 Mbit

12 Mbit

16 Mbit

16 Mbit

MAC address table

16,000

16,000

16,000

16,000

16,000

Maximum VLAN Support

4094

4094

4094

4094

4094

Dimensions (W x D x H)

440 mmx 207.5 mm x 43.6 mm

440 mmx 357.6 mm x 43.6 mm

440 mm x 267.5 mm x 43.6 mm

440 mmx 267.5 mm x 43.6 mm

440 mmx 357.6 mm x 43.6 mm

Weight (With package)

2.9 kg

4.75 kg

3.35 kg

3.6 kg

5.4 kg

MTBF

> 200,000

> 200,000

> 200,000

> 200,000

> 200,000

Warranty

5 Years

5 Years

5 Years

5 Years

5 Years

Layer 2 Features

Jumbo Frame

9216

9216

9216

9216

9216

Flow Control

✔️

✔️

✔️

✔️

✔️

STP (IEEE 802.1d)

✔️

✔️

✔️

✔️

✔️

RSTP (IEEE 802.1w)

✔️

✔️

✔️

✔️

✔️

MSTP (IEEE 802.1s)

-

-

-

-

-

Port Fast

✔️

✔️

✔️

✔️

✔️

BPDU Guard

✔️

✔️

✔️

✔️

✔️

Errdisable Recovery

✔️

✔️

✔️

✔️

✔️

Max. Aggregation Group

16

16

16

16

16

Max. Member per Group

8

8

8

8

8

Unknow Unicast Storm Suppression

✔️

✔️

✔️

✔️

✔️

Multicast / Broadcast Storm Suppression

✔️

✔️

✔️

✔️

✔️

Many-to-One Mirroring

✔️

✔️

✔️

✔️

✔️

VLAN Range

1-4094

1-4094

1-4094

1-4094

1-4094

Port-based VLAN

✔️

✔️

✔️

✔️

✔️

MAC-based VLAN

✔️

✔️

✔️

✔️

✔️

IP-based VLAN

✔️

✔️

✔️

✔️

✔️

Voice VLAN

✔️

✔️

✔️

✔️

✔️

MAC address Table

16000

16000

16000

16000

16000

RLDP

✔️

✔️

✔️

✔️

✔️

LLDP / LLDP-MED

✔️

✔️

✔️

✔️

✔️

Cable Testing

✔️

✔️

✔️

✔️

✔️

IGMP Snooping v1/v2/v3

✔️

✔️

✔️

✔️

✔️

Software Features

Ping

✔️

✔️

✔️

✔️

✔️

Traceroute

✔️

✔️

✔️

✔️

✔️

ACL Entries

1900

1900

1900

1900

1900

IP Standard ACL

✔️

✔️

✔️

✔️

✔️

MAC-based Extended ACL

✔️

✔️

✔️

✔️

✔️

IP-based Extended ACL

✔️

✔️

✔️

✔️

✔️

Port-based Rate Limit (Ingress/Egress)

✔️

✔️

✔️

✔️

✔️

SNMP v1/v2c/v3

Web Management

✔️

✔️

✔️

✔️

✔️

Management IP

10.44.77.200

10.44.77.200

10.44.77.200

10.44.77.200

10.44.77.200

HTTP/HTTPS

✔️

✔️

✔️

✔️

✔️

Cloud Management

✔️

✔️

✔️

✔️

✔️

SON (Self-Organizing Network) with IP

✔️

✔️

✔️

✔️

✔️

Camera Recognition

✔️

✔️

✔️

✔️

✔️

Loop Prevention

✔️

✔️

✔️

✔️

✔️

Loop Notification

✔️

✔️

✔️

✔️

✔️

PoE Usage Alarm

-

✔️

-

-

✔️

Protection Port

✔️

✔️

✔️

✔️

✔️

IP Source Guard

✔️

✔️

✔️

✔️

✔️

Anti-ARP Spoofing

✔️

✔️

✔️

✔️

✔️

DHCP Snooping

✔️

✔️

✔️

✔️

✔️

DHCP Client

✔️

✔️

✔️

✔️

✔️

Physical Features

Reset Button

Front

Front

Front

Front

Front

Cable Hot-swappable

✔️

✔️

✔️

✔️

✔️

Power Supply Slot

Single, fixed power supply

Single, fixed power supply

Single, fixed power supply

Single, fixed power supply

Single, fixed power supply

Power Supplies

100 - 240V AC, 1.5A

100 - 240V AC, 6A

100 - 240V AC, 2A

100 - 240V AC, 2A

100 - 240V AC, 7A

Power Consumption

≤ 28W

≤ 432W

≤ 42W

≤ 46W

≤ 448W

EEE

✔️

✔️

✔️

✔️

✔️

Fan

1

1

1

1

1

Airflow

Left-to-Rear

Left-to-Right

Left-to-Rear

Left/Right-to-Rear

Left/Right-to-Rear

Fan Adaptive Speed Adjustment

✔️

✔️

✔️

✔️

✔️

Acoustic Noise

< 45dB

Operating Temperature

0°C to 50°C (32°F to 122°F)

Storage Temperature

-40°C to 70°C (-40°F to 158°F)

Operating Humidity

10% to 90% RH

Storage Humidity

5% to 95% RH

Port Surge

6 kV

Operating Altitude (meters)

-500 to 5000

Certificate

CE, RoHS
