SKU: RG-CS83-48GT4XS-P
Category: RUIJIE NETWORK SWITCH
Availability: Unlimited
Model
Description
RG-CS83-12GT4XS-P
12 x 10M/100M/1000M electrical ports with auto-negotiation, 4 x 1GE/10GE SFP+ ports, PoE power supply, a maximum of 370 W PoE output, and built-in power module
RG-CS83-24GT4XS
24 x 10M/100M/1000M electrical ports with auto-negotiation, 4 x 1GE/10GE SFP+ ports, and built-in power module
RG-CS83-48GT4XS
48 x 10M/100M/1000M electrical ports with auto-negotiation, 4 x 1GE/10GE SFP+ ports, and built-in power module
RG-CS83-24GT4XS-P
24 x 10M/100M/1000M electrical ports with auto-negotiation, 4 x 1GE/10GE SFP+ ports, PoE power supply, a maximum of 370 W PoE output, and built-in power module
RG-CS83-48GT4XS-P
48 x 10M/100M/1000M electrical ports with auto-negotiation, 4 x 1GE/10GE SFP+ ports, PoE power supply, a maximum of 405 W PoE output, and built-in power module
Mini-GBIC-GT
1000BASE-GT mini GBIC module
MINI-GBIC-SX-MM850
Single-port 1000BASE-SX mini GBIC module (LC connector)
MINI-GBIC-LX-SM1310
Single-port 1000BASE-LX mini GBIC module (LC connector)
MINI-GBIC-LH40-SM1310
Single-port 1000BASE-LH mini GBIC module (LC connector), supporting a transmission distance of 40 km (24.85 miles)
MINI-GBIC-ZX50-SM1550
Single-port 1000BASE-ZX mini GBIC module (LC connector), supporting a transmission distance of 50 km (24.85 miles)
MINI-GBIC-ZX80-SM1550
Single-port 1000BASE-ZX mini GBIC module (LC connector), supporting a transmission distance of 80 km (24.85 miles)
MINI-GBIC-ZX100-SM1550
1000BASE-ZX mini GBIC module, supporting a transmission distance of 100 km (62.14 miles)
XG-SFP-SR-MM850
10GE LC module (62.5/125 μm: 33 m (108.27 ft.); 50/125 μm: 66 m (216.54 ft.); transmit for 300 m (984.25 ft.) when modal bandwidth is 2000 MHz * km), applicable to SFP+ ports
XG-SFP-LR-SM1310
10GE LC interface module (1310 nm), 10 km (6.21 miles), applicable to SFP+ ports
XG-SFP-ER-SM1550
10GE LC interface module (1550 nm), 40 km (24.85 miles), applicable to SFP+ ports
XG-SFP-AOC1M
10GE SFP+ fiber-optic cable, 1 m (3.28 ft.), including one cable and two interface modules
XG-SFP-AOC3M
10GE SFP+ fiber-optic cable, 3 m (3.28 ft.), including one cable and two interface modules
XG-SFP-AOC5M
10GE SFP+ fiber-optic cable, 5 m (3.28 ft.), including one cable and two interface modules
Brand: Ruijie
Model Number: RG-CS83-48GT4XS-P
Availability: In stock
Minimum order quantity: 1
Maximum order quantity: 999
Listed date: 18/12/2024
Hardware Specifications
RG-CS83-12GT4XS-P
RG-CS83-24GT4XS
RG-CS83-48GT4XS
RG-CS83-24GT4XS-P
RG-CS83-48GT4XS-P
Interface Specifications
Fixed ports
12 x 100M/1000M BASE-T ports
4 x 1GE/10GE SFP+ ports
support PoE+
24 x 100M/1000M BASE-T ports
4 x 1GE/10GE SFP+ ports
48 x 100M/1000M BASE-T ports
4 x 1GE/10GE SFP+ ports
24 x 100M/1000M BASE-T ports
4 x 1GE/10GE SFP+ ports
support PoE+
48 x 100M/1000M BASE-T ports
4 x 1GE/10GE SFP+ ports
support PoE+
Fan module
1 x fixed fan module
No fan
1 x fixed fan module
1 x fixed fan module
1 x fixed fan module
Power module
1 x fixed power module
1 x fixed power module
1 x fixed power module
1 x fixed power module
1 x fixed power module
Fixed management port
1 x console, and 1 x USB 2.0 port
System Specifications
Packet forwarding rate
78 Mpps
96 Mpps
132 Mpps
96 Mpps
132 Mpps
Switching capacity
104 Gbps
128 Gbps
176 Gbps
128 Gbps
176 Gbps
MAC address table size
16,000
ARP table size
4,000
4,000
4,000
4,000
4,000
Number of IPv4 unicast routes
6,000
Number of IPv4 multicast routes
1,000
Number of IPv6 unicast routes
2,000
Number of IPv6 multicast routes
750
Number of ACEs
Ingress: 1,750
Egress: 800
Number of VSU members
4
4
4
4
4
Dimensions and Weight
Dimensions (W x D x H)
442 mm x 220 mm x 43.6mm (17.40 in. x 8.66 in. x 1.72 in.)
442 mm x 220 mm x 43.6mm (17.40 in. x 8.66 in. x 1.72 in.)
442 mm x 220 mm x 43.6mm (17.40 in. x 8.66 in. x 1.72 in.)
442 mm x 220 mm x 43.6mm (17.40 in. x 8.66 in. x 1.72 in.)
442 mm x 220 mm x 43.6mm (17.40 in. x 8.66 in. x 1.72 in.)
Weight
3 kg (6.61 lbs)
3 kg (6.61 lbs)
3 kg (6.61 lbs)
3 kg (6.61 lbs)
3.75 kg (8.27 lbs)
CPU and Storage
CPU
1.0 GHz dual-core CPU
1.0 GHz dual-core CPU
1.0 GHz dual-core CPU
1.0 GHz dual-core CPU
1.0 GHz dual-core CPU
Flash memory
512 MB
512 MB
512 MB
512 MB
512 MB
BootROM
16 MB
16 MB
16 MB
16 MB
16 MB
SDRAM
1 GB
1 GB
1 GB
1 GB
1 GB
Data packet buffer
4 MB
4 MB
4 MB
4 MB
4 MB
Power and Consumption
Maximum power consumption
< 35 W (non-PoE)
< 405 W (PoE full load)
< 25 W
< 40 W
< 35 W (non-PoE)
< 405 W (PoE full load)
< 52 W (non-PoE)
< 460 W (PoE full load)
Maximum output power
409 W
Maximum PoE output :370W
25 W
40 W
409 W
Maximum PoE output :370W
460 W
Maximum PoE output :405W
Rated input voltage
100 V AC to 240 V AC
100 V AC to 240 V AC
100 V AC to 240 V AC
100 V AC to 240 V AC
100 V AC to 240 V AC
Maximum input voltage
90 V AC to 264 V AC, 50 Hz to 60 Hz
90 V AC to 264 V AC, 50 Hz to 60 Hz
90 V AC to 264 V AC, 50 Hz to 60 Hz
90 V AC to 264 V AC, 50 Hz to 60 Hz
90 V AC to 264 V AC, 50 Hz to 60 Hz
Environment and Reliability
MTBF
24.14 years
23.74 years
23.85 years
23.94 years
22.86 years
Primary airflow
Front-to-right and left-to-right airflow
Operating temperature
0°C to 45°C (32°F to 113°F)
Storage temperature
–40°C to +70°C (–40°F to +158°F)
Operating humidity
10% to 90% RH (non-condensing)
Storage humidity
5% to 95% RH (non-condensing)
Operating noise
27℃: < 35 dB
< 20 dB
27℃: < 32 dB
27℃: < 35 dB
27℃: < 35 dB
Interface surge protection
Power port: 6 kV(common mode)/8 kV (differential mode)
Communication port: 10 kV
Power port: 6 kV(common mode)/6 kV (differential mode)
Communication port: 10 kV
Power port: 6 kV(common mode)/6 kV (differential mode)
Communication port: 10 kV
Power port: 6 kV(common mode)/8 kV (differential mode)
Communication port: 10 kV
Power port: 6 kV(common mode)/8 kV (differential mode)
Communication port: 10 kV
Coating Conformal
Conformal coating supported (key components only)
Conformal coating supported (key components only)
Conformal coating supported (key components only)
Conformal coating supported (key components only)
Conformal coating supported (key components only)
Software Specifications
RG-CS83 Series
Feature
Description
Ethernet switching
Jumbo frame (maximum length: 9,216 bytes)
802.3az EEE
IEEE 802.1Q (4K VLANs)
Voice VLAN
Super-VLAN and private VLAN
MAC address-based VLAN, interface-based VLAN, protocol-based VLAN, and IP subnet-based VLAN
GVRP
Basic QinQ
Selective QinQ
STP, RSTP, and MSTP
ERPS (G.8032)
LLDP/LLDP-MED
IP service
ARP
DHCP client, DHCP relay, and DHCP server
DHCP snooping
DNS
DHCPv6 client, DHCPv6 relay, and DHCPv6 server
DHCPv6 snooping
Neighbor Discovery (ND) and ND snooping
IP routing
Static routing
RIP and RIPng
OSPFv2 and OSPFv3
IPv4 and IPv6 VRF
IPv4 and IPv6 PBR
Multicast
IGMP v1/v2/v3, and IGMP proxy
IGMP v1/v2 snooping
PIM-DM, PIM-SM, and PIM-SSM
MSDP
MLD v1/v2
MLD snooping v1/v2
PIM-SMv6 and PIM-SSM v6
ACL and QoS
Standard IP ACLs
Extended IP ACLs
Extended MAC ACLs
Time-based ACLs
Expert-level ACLs
ACL80
IPv6 ACL
ACL redirection
Traffic rate limiting on an interface
Congestion management: RR, SP, WRR, DRR, WFQ, SP+WRR, SP+DRR, and SP+WFQ
Congestion avoidance: tail drop
802.1p/DSCP/ToS traffic classification
Eight priority queues per interface
Security
Multiple AAA modes
RADIUS and TACAS+
Interface-based and MAC address-based 802.1x authentication
Web authentication
HTTPS
SSHv1 and SSHv2
Global IP-MAC binding
Port isolation and port security
IP source guard
SAVI
CPP and NFPP
Reliability
REUP, RLDP, DLDP
IPv4 VRRP v2/v3 and IPv6 VRRP
BFD
Link tracing, fault notification, and remote loopback based on 802.3ah (EFM)
Hot swapping of power modules and cables
Fan speed adjustment
Fan fault alarm
Device virtualization
Virtual Switching Unit (VSU)
NMS and maintenance
SPAN, RSPAN
sFlow
NTP and SNTP
FTP and TFTP
SNMP v1/v2/v3
RMON (1, 2, 3, 9)
NETCONF
CWMP (TR-069)
gRPC
Cloud and SON
PoE
RG-CS83-12GT4XS-P, RG-CS83-24GT4XS-P, and RG-CS83-48GT4XS-P:
IEEE 802.3af and 802.3at
Warm start
Interface priority
