SKU: RG-CS83-24GT4XS-PD
Category: RUIJIE NETWORK SWITCH
Availability: Unlimited
Model
Description
RG-CS83-24GT4XS-PD
24 x 10/100/1000M adaptive electrical ports, 4 x 1G/10G SFP+ ports, supporting PoE remote power supply and the maximum PoE output power of 740 W. (Purchase at least one RG-PA600I-P-F/RG-PA1000I-P-F module.)
RG-CS83-48GT4XS-PD
48 x 10/100/1000M adaptive electrical ports, 4 x 1G/10G SFP+ ports, supporting PoE remote power supply and the maximum PoE output power of 1480 W. (Purchase at least one RG-PA600I-P-F/RG-PA1000I-P-F module.)
RG-PA600I-P-F
600 W AC power module, PoE power module
RG-PA1000I-P-F
1000 W AC power module, PoE power module
Mini-GBIC-GT
1000BASE-GT mini GBIC module
Mini-GBIC-SX-MM850
Single-port 1000BASE-SX mini GBIC module (LC interface)
Mini-GBIC-LX-SM1310
Single-port 1000BASE-LX mini GBIC module (LC interface)
Mini-GBIC-LH40-SM1310
Single-port 1000BASE-LH mini GBIC module (LC interface), supporting a transmission distance of 40 km
Mini-GBIC-ZX100-SM1550
1000BASE-ZX mini GBIC module, supporting a transmission distance of 100 km
XG-SFP-SR-MM850
10G LC interface module (62.5/125 μm: 33 m; 50/125 μm: 66 m; 300-meter transmission at modal bandwidth of 2000 MHz•km), applicable to SFP+ ports
XG-SFP-LR-SM1310
10G LC interface module (1310 nm), 10 km, applicable to SFP+ ports
XG-SFP-ER-SM1550
10G LC interface module (1550 nm), 40 km, applicable to SFP+ ports
Brand: Ruijie
Model Number: RG-CS83-24GT4XS-PD
Availability: In stock
Minimum order quantity: 1
Maximum order quantity: 999
Listed date: 18/12/2024
Hardware Specifications
RG-CS83-24GT4XS-PD
RG-CS83-48GT4XS-PD
Interface Specifications
Fixed ports
24 x 10/100/1000 BASE-T ports
4 x 1G/10G SFP+ ports
PoE standards: IEEE 802.3af and 802.3at
48 x 10/100/1000 BASE-T ports
4 x 1G/10G SFP+ ports
PoE standards: IEEE 802.3af and 802.3at
Fans modules
1 x fixed fan module
1 x fixed fan module
Power modules
2 replaceable hot-swappable power supply slots
2 replaceable hot-swappable power supply slots
Fixed management ports
1 x MGMT port, 1 x console port, and 1 x USB port
1 x MGMT port, 1 x console port, and 1 x USB port
System Specifications
Packet forwarding rate
96 Mpps
132 Mpps
Switching capacity
128 Gbps
176 Gbps
MAC address table size
32,000
ARP table size
4,000
Number of IPv4 unicast routes
8,000
Number of IPv4 multicast routes
2,500
Number of IPv6 unicast routes
4,000
Number of IPv6 multicast routes
1,200
Number of ACEs
Ingress: 3,500
Egress:1,500
Number of VSU members
4
VLAN translation
4,094
Dimensions and Weight
Dimensions (W x D x H)
442 x 420 x 43.6 mm (17.40 x 16.54 x 1.72 in), 1 RU
Weight (empty chassis and fan modules)
4.3 kg (9.48 lbs)
4.6 kg (10.14 lbs)
CPU and Storage
CPU
Dual cores, with the clock speed of 1.2 GHz
Flash memory
2 GB
BootROM
16 MB
SDRAM
1 GB
Data packet buffer
3 MB
Power and Consumption
Maximum power consumption
< 65 W (non-PoE)
< 810 W (PoE full load)
< 75 W (non-PoE)
< 1570 W (PoE full load)
Maximum output power
RG-PA600I-P-F: 600 W (PoE: 370 W)
RG-PA1000I-P-F:
176 V AC to 290 V AC, 1000W
90 V AC to 176 V AC, 930 W (PoE: 740 W)
Rated input voltage
RG-PA600I-P-F:
AC: 100 V AC to 240 V AC, 50/60 Hz
HVDC: 240 V DC
RG-PA1000I-P-F:
AC: 100 V AC to 240 V AC, 50/60 Hz
HVDC: 240 V DC
Maximum input voltage
RG-PA600I-P-F:
AC: 90 V AC to 264 V AC, 47/63 Hz
HVDC: 192 V DC to 288 V DC
RG-PA1000I-P-F:
AC: 90 V AC to 264 V AC, 47/63 Hz
HVDC: 192 V DC to 288 V DC
Environment and Reliability
MTBF
≥ 356,000 hours (dual power modules)
≥ 208,000 hours (single power module)
≥ 315,000 hours (dual power modules)
≥ 193,000 hours (single power module)
Primary Airflow
Left-to-right and front-to-right airflow
Operating temperature
0°C to 45°C (32°F to 113°F)
Storage temperature
-40°C to +70°C (-40°F to +158°F)
Operating humidity
10% to 90% RH (non-condensing)
Storage humidity
5% to 95% RH (non-condensing)
Operating noise
27°C: 51.6 dB
45°C: 57.4 dB
27°C: 51.6 dB
45°C: 58.3 dB
Interface surge protection
Power port: 6 kV/6 kV
Telecom port: 10 kV (MGMT port: 4 kV)
Power port: 6 kV/6 kV
Telecom port: 10 kV (MGMT port: 4 kV)
Coating Conformal
Conformal coating supported (key components only)
Conformal coating supported (key components only)
RG-CS83-PD Series
Feature
Description
Ethernet switching
Jumbo frame (maximum length: 9216 bytes)
IEEE 802.1Q (4K VLANs)
Voice VLAN
Super VLAN and private VLAN
MAC VLAN, port-based VLAN, protocol-based VLAN, and IP-subnet based VLAN
GVRP
Basic QinQ
Selective QinQ
STP, RSTP, and MSTP
ERPS (G.8032)
LLDP/LLDP-MED
LACP (IEEE 802.3ad)
IP service
ARP
DHCP client, DHCP relay, and DHCP server
DHCP snooping
DNS
DHCPv6 client and DHCPv6 relay
DHCPv6 snooping
Neighbor Discovery (ND) and ND snooping
IP routing
Static routing
RIP, RIPng
OSPFv2, OSPFv3, IS-ISv4, ISv4, and IS-ISv6
BGP4 and BGP4+
IPv4 and IPv6 VRF
IPv4 and IPv6 PBR
Multicast
IGMP v1/v2/v3, and IGMP proxy
IGMP v1/v2/v3 snooping
PIM-DM, PIM-SM, and PIM-SSM
MSDP
MLD v1/v2
MLD snooping v1/v2
PIM-SMv6, PIM-SSM v6
ACL and QoS
Standard IP ACLs
Extended IP ACLs
Extended MAC ACLs
ACL80
IPv6 ACL
ACL redirection
Port traffic identification
Port traffic rate limiting
802.1p/DSCP/ToS traffic classification
Eight priority queues per interface
Traffic policing: CAR
Congestion management: RR, SP, WRR, DRR, WFQ, SP+WRR, SP+DRR, and SP+WFQ
Congestion avoidance: tail drop, RED, and WRED
Rate limiting in each queue
Security
Multiple AAA modes
RADIUS and TACAS+
Port-based and MAC-based 802.1x authentication
Web authentication
Allowlist
HTTPS
SSHv1, SSHv2
Global IP-MAC binding
ICMP
Port isolation and port security
IP Source Guard
SAVI
Gateway ARP anti-spoofing
CPP(CPU Protection Policy)
NFPP( Network Foundation Protection Policy)
Strict and loose RPF
uRPF ignoring default routes
Reliability
REUP, RLDP, DLDP
IPv4 VRRP v2/v3 and IPv6 VRRP
BFD
Link tracing, fault notification, and remote loopback based on 802.3ah (EFM)
Hot swapping of power modules and cables
3-level fan speed adjustment
Fan fault alarm
Device virtualization
Virtual Switching Unit (VSU)
NMS and maintenance
SPAN, RSPAN, and ERSPAN
sFlow
NTP and SNTP
FTP and TFTP
SNMP v1/v2/v3
RMON (1, 2, 3, 9)
NETCONF
CWMP (TR-069) standard protocol
gRPC
Cloud and SON
PoE
IEEE 802.3af and 802.3at
Uninterruptible power supply upon hot start
Port priority
