SKU: RG-AP840-I
Category: ruijie access points
Availability: Unlimited
Model
Description
RG-AP840-I
High-density Wi-Fi 6 (802.11ax) indoor wireless access point, concurrent dual-band dual-radio (2x2:2 in 2.4GHz, 4x4:4 in 5GHz), up to 6 total spatial streams and maximum 5.2Gbps wireless throughput, 3 Gigabit Ethernet ports (LAN3 port supports IoT sensor extension), integrated with BLE, support PoE+ and local power supply(PoE+ adapters are sold separately, which could be purchased from Ruijie while DC Power adapters should be purchased from third-party vendors separately if needed)
RG-E-130(GE)
1-port PoE adapter (1000Base-T, PoE+/ 802.3at)
Brand: Ruijie
Model Number: RG-AP840-I
Availability: In stock
Minimum order quantity: 1
Maximum order quantity: 999
Listed date: 03/08/2024
Model | RG-AP840-I | |
Hardware specifications | ||
Radio | Dual-radio dual-band： Radio 1: 2.4G 11n: 2×2 MIMO Radio 2: 5G 11ax: 4x4 MIMO | |
Protocol | Supports standard 802.11ax, dual-radio dual-band, concurrent 802.11ax and 802.11a/b/g/n/ac | |
Operating Bands | 802.11b/g/n ：2.4G ~ 2.483GHz 802.11a/n/ac/ax ： 5.150～5.350GHz，5.47～5.725GHz，5.725～5.850GHz (vary depending on different countries) | |
Spatial Streams | Up to 6: 2×2:2 in 2.4GHz , 4×4:4 in 5GHz | |
Max Throughput | Maximum throughput of 2.4G: 400Mbps Maximum throughput of 5G: 4.8Gbps Maximum throughput per AP: 5.2Gbps | |
Modulation | OFDM：BPSK@6/9Mbps，QPSK@12/18Mbps，16-QAM@24Mbps，64-QAM@48/54Mbps DSSS：DBPSK@1Mbps，DQPSK@2Mbps，and [email protected]/11Mbps MIMO-OFDM：BPSK, QPSK, 16QAM, 64QAM, 256QAM and 1024QAM OFDMA (up to 1024-QAM) | |
Receiver Sensitivity | 11b：-96dBm（1Mbps），-93dBm（5Mbps），-89dBm（11Mbps） 11a/g：-91dBm（6Mbps），-85dBm（24Mbps），-80dBm（36Mbps），-74dBm（54Mbps） 11n：-90dBm（MCS0），-70dBm（MCS7），-89dBm（MCS8），-68dBm（MCS15） 11ac HT20：-88dBm（MCS0）, -63dBm（MCS9） 11ac HT40：-85dBm（MCS0）, -60dBm（MCS9） 11ac HT80：-82dBm（MCS0）, -57dBm（MCS9） 11ax HT80：-82dBm（MCS0）, -57dBm（MCS9）, -52dBm（MCS11） 11ax HT160：-80dBm（MCS0）, -49dBm（MCS11） | |
Antenna | Integrated antenna design | |
Antenna Gain | 2.4G: 3dBi 5G: 3dBi | |
Service Ports | 3 10/100/1000M Ethernet ports (The LAN1 Port supports PoE in, LAN3 Port supports LAN & IoT module expansion with PoE out) | |
Management Port | 1 console port | |
USB | 1 USB 2.0 port | |
IoT Capability | BLE | |
Reset Button | Support | |
Anti-theft Lock | Support | |
LED Indicator | 1 LED indicator (Supports red, green, blue, orange and flashing mode, which indicates device access. The indicator can be switched off to silent mode.) | |
Transmit Power | ≤100mw（20dBm） (vary depending on different countries) | |
Adjustable Power | 1dBm | |
Power Supply | Local power supply (DC 48V/1A) (DC Power adapters should be purchased from third-party vendors separately if needed.) PoE+ (802.3at) PoE (802.3af) – Not recommended: 5G radio is degraded to 2x2 MIMO, and the PoE out of the LAN3/ IoT port is disabled | |
Power Consumption | ＜25.4W | |
Physical Specifications | ||
Temperature | Operating Temperature: -10°C to 50°C | |
Storage Temperature: -40°C to 70°C | ||
Humidity | Operating Humidity: 5% to 95% (non-condensing) | |
Storage Humidity: 5% to 95% (non-condensing) | ||
Installation Mode | Ceiling/wall-mountable | |
Dimensions (W x D x H) | 220mm ×220mm x48.85mm（Height of the AP only, excluding the mount kit） | |
Weight | 1.30kg | |
MTBF | 250,000 hours | |
Certifications and Compliance | ||
Safety Standard | GB4943, EN/IEC 60950-1 | |
EMC Standard | GB9254, EN301 489 EN 55032 , EN 61000, EN 55035 | |
Health Standard | EN 62311 | |
Radio Standard | SRRC, EN300 328, EN301 893 | |
Software Specifications | ||
WLAN | Maximum clients per AP | 1024 (Recommended Clients: 64) |
BSSID capacity | Up to 32 | |
SSID hiding | Support | |
5G Priority (Band Steering) | Support | |
Configuring the authentication mode, encryption mechanism and VLAN attributes for each SSID | Support | |
Remote Intelligent Perception Technology (RIPT) | Support | |
Intelligent device recognition technology | Support | |
Intelligent load balancing based on the number of users or traffic | Support | |
STA control | SSID/radio-based | |
Bandwidth control | STA/SSID/AP-based bandwidth control | |
Data encryption | WPA（TKIP）, WPA-PSK, WPA2（AES）, WPA3, WEP（64/128 bits） | |
PSK and web authentication | Support | |
PPSK authentication (For Employee) | Support (require wireless controller) | |
802.1x authentication | Support | |
PEAP authentication | Support | |
Data frame filtering | Whitelist, static/dynamic blacklist | |
User isolation | Support | |
Rogue AP detection and countermeasure | Support | |
Dynamic ACL assignment | Support | |
RADIUS | Support | |
CPU Protection Policy (CPP) | Support | |
Network Foundation Protection Policy (NFPP) | Support | |
IP | IPv4 and IPv6 address | Support |
Multicast routing | Multicast to unicast conversion | |
DHCP service | DHCP Snooping, Option 82, Server, Client | |
Management and Maintenance | Supported wireless LAN controllers | Ruijie WS Series Wireless Controller Ruijie MACC-Base Software Controller Ruijie Cloud (Public Cloud) |
Management protocol | Telnet, SSH, TFTP, Web | |
Wireless Intelligent AI Optimization Service (WIS) | Support | |
SNMP | SNMPV1,V2c,V3 | |
Syslog / Debug | Support | |
FAT/FIT/MACC mode switching | Factory default firmware supports FAT (standalone) or FIT mode (WS controller) or MACC mode (Ruijie MACC-Base or Ruijie Cloud) management | |
